Tesla Model X Standard Range

Years of Production
When the car first came out and when they stopped making it
2019 - 2020
Price USA (used)
Estimated pre-owned price
$41,898

Trims

Currently Produced

Tesla Model X Standard Range

Technical Specifications of Tesla Model X Standard Range

General Info

Years of Production
When the car first came out and when they stopped making it
2019 - 2020
Country of Manufacture
Country where final assembly of the car took place.
Holland, USA
Current Status
Announced (planned), Pre-order (reservations open), Produced (on sale), Discontinued (no longer made)
Discontinued
Body Style
Refers to the car's shape & design (sedan, SUV, hatchback)
SUV Tesla Model X Standard Range

Range and Efficiency

Range EPA
Estimated range on a full battery according to official EPA ratings (USA)
258 mi
Range WLTP
Range according to WLTP ratings.
TEL: car in its lightest configuration.
TEH: car in its heaviest configuration.
TEL
TEH
233 mi No Data
Efficiency
Energy consumption per distance driven. Lower figures indicate better efficiency.
kWh/100 mi
Wh/mi
33.3 kWh 333 Wh

Battery and Charging

Battery Capacity
Nominal: total amount of energy the car’s battery can hold. Usable: actual amount of energy you can access.
Nominal
Usable
75 kWh 72.5 kWh
Max Charging Power
Max electric power the car can accept for charging, determined by its on-board charger (AC) and battery (DC)
AC
DC
11.5 kW 100 kW
Charge Port
The car's charge port type. It affects charging speed and station compatibility.
Tesla
Tesla charge port

Performance

Drive Type
Which wheels are powered (all, rear, or front) by the electric motor(s)
AWD
Engine
Torque: pulling force of the engine. Power: how quickly it can turn the wheels with that force.
Power
Torque
250 kW (335 hp) 406 lb-ft
0-60 mph
Acceleration time from 0 to 60 mph (USA) or 0 to 100 km/h (Europe)
4.6 s
Top Speed
The fastest the car can go (maximum speed)
155 mph
0.00 s
00 mph

Dimensions

Length
Car's body length (front to back bumper)
198.9 in
Width
Car's body width including or excluding side mirrors
with Mirrors
w/o Mirrors
89.4 in 78.7 in
Height
Car's body height (from ground to highest point)
66.3 in
Wheelbase
Distance between centers of front and rear wheels (affects ride and handling)
116.7 in

Cargo and Towing

Number of Seats
Total passenger capacity of the car (including driver)
5
Curb Weight
Car's weight without passengers or cargo
5421 lb
Cargo Volume
Trunk: cargo capacity (rear seats up).
Max: cargo capacity (rear seats folded).
Frunk: cargo capacity in the front hood.
Trunk
Max
Frunk
12.6 ft3 85.8 ft3 6.6 ft3
Towing Capacity
Maximum weight the car can tow safely with a trailer that has its own brakes
5000 lb
Last Updated:
March 28, 2024
Download Specs PDF

How Far Can You Go in Tesla Model X Standard Range

The map shows how far you can go with a fully-charged battery:
  • Light green area: Round-trip
  • Dark green area: One-way
For the most accurate results, please allow the widget to use your location.

Charging Tesla Model X Standard Range

Slow (AC)
Fast (DC)

Home and Office (AC) Charging

NEMA 5-15

Socket specs
Socket specs
120 V, 15 A, 1-phase
Socket output
Socket output
1.8 kW
Charging 20-80%
Charging 20-80%
26 h 51 min (~5 mph)

NEMA 5-20

Socket specs
Socket specs
120 V, 20 A, 1-phase
Socket output
Socket output
2.4 kW
Charging 20-80%
Charging 20-80%
20 h 08 min (~6 mph)

NEMA 6-20

Socket specs
Socket specs
240 V, 20 A, 1-phase
Socket output
Socket output
4.8 kW
Charging 20-80%
Charging 20-80%
10 h 04 min (~13 mph)

NEMA 14-30

Socket specs
Socket specs
240 V, 30 A, 1-phase
Socket output
Socket output
7.2 kW
Charging 20-80%
Charging 20-80%
06 h 43 min (~19 mph)

NEMA 14-50

Socket specs
Socket specs
240 V, 50 A, 1-phase
Socket output
Socket output
12 kW
Charging 20-80%
Charging 20-80%
04 h 12 min (~31 mph)
Charging power is limited by the car’s on-board charger (11.5 kW)

NEMA 6-50

Socket specs
Socket specs
240 V, 50 A, 1-phase
Socket output
Socket output
12 kW
Charging 20-80%
Charging 20-80%
04 h 12 min (~31 mph)
Charging power is limited by the car’s on-board charger (11.5 kW)

Fast (DC) Charging

CCS DC 50 kW

Socket output
Socket output
50 kW
Charging 20-80%
Charging 20-80%
01 h 01 min (~128 mph)
Tesla needs an adapter to charge at CCS DC stations

CCS DC 100 kW

Socket output
Socket output
100 kW
Charging 20-80%
Charging 20-80%
00 h 33 min (~241 mph)
Tesla needs an adapter to charge at CCS DC stations

CCS DC 150 kW

Socket output
Socket output
150 kW
Charging 20-80%
Charging 20-80%
00 h 33 min (~241 mph)
Tesla needs an adapter to charge at CCS DC stations Charging power is limited by the car’s DC charging capability (100 kW)

CCS DC 200 kW

Socket output
Socket output
200 kW
Charging 20-80%
Charging 20-80%
00 h 33 min (~241 mph)
Tesla needs an adapter to charge at CCS DC stations Charging power is limited by the car’s DC charging capability (100 kW)

CCS DC 250 kW

Socket output
Socket output
250 kW
Charging 20-80%
Charging 20-80%
00 h 33 min (~241 mph)
Tesla needs an adapter to charge at CCS DC stations Charging power is limited by the car’s DC charging capability (100 kW)

CCS DC 350 kW

Socket output
Socket output
350 kW
Charging 20-80%
Charging 20-80%
00 h 33 min (~241 mph)
Tesla needs an adapter to charge at CCS DC stations Charging power is limited by the car’s DC charging capability (100 kW)

Supercharger V2 Split 75 kW

Socket output
Socket output
75 kW
Charging 20-80%
Charging 20-80%
00 h 41 min (~192 mph)

Supercharger V2 150 kW

Socket output
Socket output
150 kW
Charging 20-80%
Charging 20-80%
00 h 33 min (~241 mph)
Charging power is limited by the car’s DC charging capability (100 kW)

Supercharger V3 250 kW

Socket output
Socket output
250 kW
Charging 20-80%
Charging 20-80%
00 h 33 min (~241 mph)
Charging power is limited by the car’s DC charging capability (100 kW)
Last Updated:
March 28, 2024
Open Charging Calculator

About Tesla Model X Standard Range

The Tesla Model X Standard Range is an all-electric all-wheel drive SUV. It came out in 2019 replacing the older Tesla Model X 75D. Tesla stopped making the Standard Range in 2020. You can still find Tesla Model X Standard Range on the used car market, with prices starting around $41,898.

The Tesla Model X Standard Range has a 75 kWh battery pack, allowing it to travel up to 218 mi on a single charge. The car has an average efficiency of 33.3 kWh per 100 miles (or 333 Wh/mile) — ranked №347 out of 586 electric vehicles.

Frequently Asked Questions

How fast is Tesla Model X Standard Range

The Tesla Model X Standard Range can accelerate from 0 to 60 mph in 4.6 seconds (ranked â„–144 out of 596 electric vehicles) and reach a top speed of 155 mph.

The car’s powertrain delivers up to 250 kW (335 hp) of power and 406 lb-ft of torque.

Real-world range of Tesla Model X Standard Range

The estimated real-world range for Tesla Model X Standard Range falls between 196–240 miles, ranking it №353 out of 596 electric vehicles. Several conditions can influence this range:

  • Speed: The battery drains faster at higher speeds.
  • Temperature: Extreme temperatures can impact range.
  • Terrain: Range is reduced on hilly or mountainous terrain.
  • Driving style: Aggressive driving behaviors, such as frequent acceleration and braking, decrease efficiency.
  • Feature utilization: Climate control and media system usage also affect range.

These figures are approximations, and your actual driving range may vary. When planning trips, consider these factors and be prepared for potential charging stops.

For trip planning assistance, utilize the EV Navigation interactive map.

Tesla Model X Standard Range charge port type?

The Tesla Model X Standard Range in the USA comes with a Tesla charging port. It can be charged at home using a standard domestic socket or at any public AC charging station with the compatible cable. It's important to note that the car's on-board charger (inverter) limits the maximum AC charging rate to 11.5 kW, resulting in approximately 31 miles of range added per hour of charging.

For significantly faster charging, public DC fast-charging stations are available. Although the car can achieve a maximum DC charging rate of 100 kW, factors such as battery temperature and charge level may affect the actual charging speed.

Use Green Cars Compare Charging Calculator to estimate charging time, rate, and cost.

Tesla Model X Standard Range dimensions and weight?

Tesla Model X Standard Range comes in the following dimensions:

  • Length: 198.9 in
  • Width: 89.4 in (including side mirrors) or 78.7 in (excluding side mirrors)
  • Height: 66.3 in
  • Wheelbase: 116.7 in (distance between the center of the front and rear wheels)
  • Curb weight: 5421 lbs (weight of the empty car, no people or cargo)
Tesla Model X Standard Range cargo capacity?

The rear cargo area of the Tesla Model X Standard Range provides 12.6 cubic feet of space when the rear seats are upright (ranked â„–431 out of 596 electric vehicles).

Folding these seats down unlocks a maximum cargo capacity of 85.8 cubic feet (ranked â„–431 out of 596 electric vehicles).

In addition, the car has a frunk, a front compartment with 6.6 cubic feet dedicated to smaller items.

Tesla Model X Standard Range towing capacity?
The Tesla Model X Standard Range has a towing capacity (braked) of up to 5000 lbs (maximum weight the car can tow safely with a trailer that has its own brakes).
